General data

Operate time at U

Release time without diode in parallel (non-latching), typ. / max.

Release time with diode in parallel (non-latching), typ. / max.

Bounce time at closing contact, typ. / max.

Maximum switching rate without load

Ambient temperature

Thermal resistance

Maximum permissible coil temperature

Vibration resistance (function)

Shock resistance, half sinus, 11 ms

Degree of protection

Needle flame test

Mounting position

Processing information

Weight (mass)

Terminal surface

Resistance to soldering heat

4 ms / 5 ms

1 ms / 3 ms

4 ms / 6 ms

1 ms / 5 ms

50 operations/s

-55° C ... +85° C

< 85 K/W

115° C

10 G

10 to 500 Hz

10 G / 30 G (function)

30 G (damage)

immersion cleanable, IP 67

application time 10 s,

any

Ultrasonic cleaning is not recommended

max. 5 g

SnCu 0.7

260° C / 10 s

All data refers to 23° C unless otherwise specified.

MT2 Relay

Tube for THT version - 25 relays per stick, 1’000 relays per box

Packing

Capacitance

between coil and contacts

between adjacent contact sets

between open contacts

RF Characteristics

Isolation at 100 / 900 MHz

Insertion loss at 100 / 900 MHz

V.S.W.R. at 100 / 900 MHz

max. 4 pF

max. 2 pF

max. 2 pF

- 31.8 dB / - 14.2 dB

- 0.02 dB / - 0.97 dB

1.03 / 1.31

High Frequency Data

Page 7 (9)

108-98006 Rev. C

Dimensions in mm
