MT2 Relay

Insulation

Insulation resistance at 500 Vdc

Dielectric test voltage (1 min)

between coil and contacts

between adjacent contact sets

between open contacts

Surge voltage resistance

according to FCC 68 (10 / 160 ms) and IEC (10 / 700 ms)

between coil and contacts

between adjacent contact sets

between open contacts

> 109 W

1050 Vrms

750 Vrms

1500 V

Page 6 (9)

108-98006 Rev. C

Max. DC load breaking capacity

DC current [A]
