Section 8 User Break Controller (UBC)

Rev. 2.00 Sep. 24, 2008 Page 179 of 1468

REJ09B0412-0200

8.4.3

Condition Match Flag

Condition match flags are set when the break conditions match. The condition match flags of the

UBC are listed in table 8.2.

Table 8.2

List of Condition Match Flags

Flag Bit

Source

BRCRA

CMFCPA (bit 13)

Indicates that the condition matches in the CPU cycle

for channel A

BRCRB

CMFCPB (bit 13)

Indicates that the condition matches in the CPU cycle

for channel B

BRCRC

CMFCPC (bit 13)

Indicates that the condition matches in the CPU cycle

for channel C

BRCRD

CMFCPD (bit 13)

Indicates that the condition matches in the CPU cycle

for channel D
