Section 9 Bus Controller (BSC)
Rev. 2.00 Sep. 24, 2008 Page 275 of 1468
REJ09B0412-0200
9.9.7
Wait Control
In the data cycle of the address/data multiplexed I/O interface, program wait insertion and pin wait
insertion by the
WAIT pin are enabled in the same way as in the basic bus interface. For details,
refer to section 9.6.4, Wait Control.
Wait control settings do not affect the address cycles.
9.9.8
Read Strobe (
RD) Timing
In the address/data multiplexed I/O interface, the read strobe timing of data cycles can be modified
in the same way as in basic bus interface. For details, refer to section 9.6.5, Read Strobe (
RD)
Timing.
Figure 9.34 shows an example when the read strobe timing is modified.
