DESCRIPTION
L6258E is a dual full bridge for motor control applications realized in BCD technology, with the capability of driving both windings of a bipolar stepper motor or bidirectionally control two DC motors.

■ ABLE TO DRIVE BOTH WINDINGS OF A BIPOLAR STEPPER MOTOR OR TWO DC MOTORS
■ OUTPUT CURRENT UP TO 1.2A EACH WINDING
■ WIDE VOLTAGE RANGE: 12V TO 40V
■ FOUR QUADRANT CURRENT CONTROL, IDEAL FOR MICROSTEPPING AND DC MOTOR CONTROL
■ PRECISION PWM CONTROL
■ NO NEED FOR RECIRCULATION DIODES
■ TTL/CMOS COMPATIBLE INPUTS
■ CROSS CONDUCTION PROTECTION
■ THERMAL SHUTDOW
