General Note

TT Electronics reserves the right to make changes in product specification without

notice or liability. All information is subject to TT Electronics’ own data and is

considered accurate at time of going to print.

OP550, OP552, OP555, OP560, OP565,

OP750 Series

Issue A

08/2016

Page 3

OPTEK Technology, Inc.

1645 Wallace Drive, Carrollton, TX 75006|Ph: +1 972 323 2200

www.optekinc.com | www.ttelectronics.com

Absolute Maximum Ratings (TA = 25° C unless otherwise noted)

Storage Temperature Range

-40

o C to +100o C

Operating Temperature Range

OP550, OP555, OP560, OP565, OP750

OP552

-40

o C to +100o C

-40

o C to +85o C

Collector-Emitter Voltage

OP550, OP552, OP555, OP560, OP750

OP565

30 V

15 V

Emitter-Collector Voltage

5 V

Lead Soldering Temperature [1/16 inch (1.6 mm) from case for 5 seconds with soldering iron]

260° C

(1)

Power Dissipation

OP550, OP552, OP555, OP560, OP565

OP750

100 mW

(2)

200 mW

(2)

Electrical Specifications
