AD8698

Rev. 0 | Page 5 of 20

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

±15 V

Input Voltage

Differential Input Voltage

Output Short-Circuit Duration

to Gnd

Indefinite

Storage Temperature Range

R, RM Packages

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

Junction Temperature Range

R, RM Packages

−65°C to +150°C

Lead Temperature Range

(Soldering, 60 Sec)

+300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

θ

JA

for devices soldered in circuit boards for surface-mount

packages.

Table 4. Thermal Resistance

Package Type

θ

JA

θ

JC

Unit

MSOP-8 (RM)

210

45

°C/W

SOIC-8 (R)

158

43

°C/W

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 1000 V readily accumulate on the

human body and test equipment and can discharge without detection. Although this product features

proprietary ESD protection circuitry, permanent damage may occur on devices subjected to high energy

electrostatic discharges. Therefore, proper ESD precautions are recommended to avoid performance

degradation or loss of functionality.
