Page 1 of 2

Maximum Ratings

Operating Temperature

-55°C to 85°C

Storage Temperature

-55°C to 100°C

Absolute Max. Supply Voltage (Vcc)

8V

Absolute Max. Tuning Voltage (Vtune)

7V

All specifications

50 ohm system

REV. D

M151108

EDR-11090MP

ROS-2940C+

RAV

150930

Electrical Specifications

ROS-2940C+

Pin Connections

RF OUT

10

VCC

14

V-TUNE

2

GROUND

1,3,4,5,6,7,8,9,11,12,13,15,16

MODEL

FREQ.

POWER

PHASE NOISE

TUNING

NON

HARMONICS PULLING PUSHING

DC

NO.

(MHz)

OUTPUT dBc/Hz SSB at offset

HARMONIC

(dBc)

pk-pk

(MHz/V)

OPERATING

(dBm)

frequencies,kHz

VOLTAGE SENSI- PORT

3 dB

SPURIOUS

@12 dBr

POWER

RANGE TIVITY CAP MODULATION

(dBc)

(MHz)

Typ.

(V)

(MHz/V) (pF) BANDWIDTH

Vcc Current

(MHz)

(volts)

(mA)

Min. Max.

Typ.

1

10 100 1000 Min. Max.

Typ.

Typ.

Typ.

Typ.

Typ.

Max.

Typ.

Typ.

Max.

ROS-2940C+ 2935 2940

+4.5

-87 -115 -134 -154

0.5

5.0 13 - 14

20

150

-90

-17

-10

0.6

0.8

7

40

Voltage Controlled Oscillator

Low Noise

2935 to 2940 MHz

Surface Mount

• wireless communications

• military & avionics

Applications

• linear tuning characteristics

• low phase noise

• low pulling

• low pushing

• aqueous washable

Features

Permanent damage may occur if any of these limits are exceeded.

Outline Drawing

Outline Dimensions (

)

inch

mm

A

B

C

D

E

F

G

H

J

K

L

M

N

P

Q

R

S

T

wt.

.500 .500 .220 .100 .080 .115 .060 .040 .540 .060 .100 .135 .135 .115 .140 .070 .150 .070 grams

12.70 12.70 5.59 2.54 2.03 2.92 1.52 1.02 13.72 1.52 2.54 3.43 3.43 2.92 3.56 1.78 3.81 1.78

1.2

Demo Board MCL P/N: TB-10

Suggested PCB Layout (PL-012)

+RoHS Compliant

The +Suffix identifies RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualifications

Suggested Layout,

Tolerance to be within ±.002

CASE STYLE: CK1113
