MP3313 – 3-CHANNEL, LINEAR/EXPONENTIAL DIMMING, WLED DRIVER W/ I2C
MP3313 Rev1.0
www.MonolithicPower.com
11
8/2/2017
MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.
© 2017 MPS. All Rights Reserved.
PIN FUNCTIONS
Pin #
Name
I/O
Description
A1
LED1
I
Current sink for LED1.
A2
A0
I
LSB of I2C interface address select. If A0 is floating, it must be pulled up or
down externally. If A0 is pulled low, the I2C address LSB is 0. If A0 is pulled
high, the I2C address LSB is 1.
A3
GND
I
Ground.
B1
LED2
I
Current sink for LED2.
B2
SDA
I/O
I2C interface data signal input.
B3
SW
I
Drain connection of the internal low-side MOSFET for boost converter.
C1
LED3
I
Current sink for LED3.
C2
SCL
I
I2C interface clock signal input.
C3
OUT
O
Boost converter output connection.
D1
PWM
I
PWM dimming input signal. Apply a 50Hz to 50kHz PWM pulse to the PWM
pin for analog dimming.
D2
EN
I
IC enable input. Drive EN to logic high to enable the IC. Drive EN to logic low
longer than 2.5ms to shut down the IC.
D3
VIN
I
Power supply input with 2.7V to 5.5V. Connect a ceramic capacitor close to
VIN to bypass the IC.
