Input

Description

voltage

Type

Order No.

Pcs./ Pkt.

PLC interface, consisting of

base terminal block PLC-BSP…ACT and

pluggable miniature relay

(see catalog part 6, page 32),

for mounting on

3

3

3

3

equipped with

power contact relay

PLC-RSP- 24DC/ACT

29 67 34 5

10

Technical data

Input data

Permissible input voltage range

Input circuit

24 V DC

24 V DC

see diagram catalog part 6, page 25

9 mA

5 ms

8 ms

operation indicator, polarity protection diode, damping diode

Output data

Contact type

Contact material

Max. switching voltage

Min. switching voltage

Limiting continuous current

Max. inrush current

Min. switching current

Max. power rating, ohmic load:

24 V DC

48 V DC

60 V DC

110 V DC

220 V DC

250 V AC

Min. switching capacity

AgSnO

12 V AC/DC

6 A

on request

10 mA

140 W

20 W

18 W

23 W

40 W

1500 VA

120 mW

General data

Test voltage input/output

Ambient temperature range

Duty type rating

Inflammability class

Mechanical service life

Standards/regulations

Installation position/assembly

Type of connection

4 kV, 50 Hz, 1 min.

– 20 °C to + 60 °C

100 % ED

V0 in acc. with UL 94

IEC 664/IEC 664 A/DIN VDE 0110, contamination class 3,

Surge voltage category III, DIN VDE 0160 (in relev. parts),

IEC 255/DIN VDE 0435 (in relev. parts), DIN VDE 0106-101: 1986-11,

as desired, in rows with zero spacing

spring cage connection

terminal blocks of adjacent modules, the PLC-ATP separating plate

(see catalog part 6, page 34) should be installed.

modules, the PLC-ATP separating plate (see catalog part 6, page

34) should be installed.

Notes:

Type of housing: polyamide PA non-reinforced,

Color: green, see catalog part 6, page 149

Marking systems and mounting material, see catalog part 3/4.

The rated cross section (see catalog part 6, page 151) refers to

untreated conductors without ferrules.

For the protection of input and output, inductive loads must be

dampened with an effective protection circuit.

The PLC-ATP separating plate (see catalog part 6, page 34) must

always be installed at the beginning and end of a PLC terminal

strip.

PLC Actuator Interface with Relay

– now also with spring cage connection system!
