AD8375ACPZ-R7 Scheda tecnica(PDF) 5 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
AD8375ACPZ-R7 Scheda tecnica(HTML) 5 Page - Analog Devices |
|
|
5 / 24 page  Data Sheet AD8375 Rev. B | Page 5 of 24 ABSOLUTE MAXIMUM RATINGS Table 3. Parameter Rating Supply Voltage, VPOS 5.5 V PWUP, A0 to A4 −0.6 V to (VPOS + 0.6 V) Input Voltage, VIN+, VIN− −0.15 V to +4.15 V DC Common Mode VCOM ± 0.25 V VCOM ±6 mA Internal Power Dissipation 825 mW θJA (Exposed Paddle Soldered Down) 63.6°C/W θJC (At Exposed Paddle) 14.6°C/W Maximum Junction Temperature 140°C Operating Temperature Range −40°C to +85°C Storage Temperature Range −65°C to +150°C Stresses at or above those listed under Absolute Maximum Ratings may cause permanent damage to the product. This is a stress rating only; functional operation of the product at these or any other conditions above those indicated in the operational section of this specification is not implied. Operation beyond the maximum operating conditions for extended periods may affect product reliability. ESD CAUTION |
|
|
