4 / 15 page  ADL5331 Data Sheet Rev. A | Page 4 of 15 ABSOLUTE MAXIMUM RATINGS Table 2. Parameter Rating Supply Voltage VPS1 5.5 V Supply Voltage VPS2 5.5 V VPS2 to VPS1 ±200 mV RF Input Power 5 dBm at 50 Ω OPHI, OPLO 5.5 V ENBL VPS1 GAIN VPS1 Internal Power Dissipation 1.2 W θJA (with Pad Soldered to Board) 56.1°C/W Maximum Junction Temperature 150°C Operating Temperature Range −40°C to +85°C Storage Temperature Range −65°C to +150°C Stresses at or above those listed under Absolute Maximum Ratings may cause permanent damage to the product. This is a stress rating only; functional operation of the product at these or any other conditions above those indicated in the operational section of this specification is not implied. Operation beyond the maximum operating conditions for extended periods may affect product reliability. ESD CAUTION |
|
|
