background image
ADRF6520
Data Sheet
Rev. 0 | Page 6 of 29
ABSOLUTE MAXIMUM RATINGS
Table 2.
Parameter
Rating
Supply Voltages, VPS, VPSD
3.6 V
ENBL, LE, CLK, DATA, SDIO
VPSD + 0.5 V
INP1, INM1, INP2, INM2,
VPS + 0.5 V
OPP1, OPM1, OPP2, OPM2
VPS + 0.5 V
OFS1, OFS2, VRMS
VPS + 0.5 V
VGN1, VGN2
VPS + 0.5 V
Internal Power Dissipation
1.53 W
Maximum Junction Temperature
125°C
Operating Temperature Range
−40°C to +85°C
Storage Temperature Range
−65°C to +150°C
Lead Temperature (Soldering 60 sec)
300°C
Stresses at or above those listed under Absolute Maximum
Ratings may cause permanent damage to the product. This is a
stress rating only; functional operation of the product at these
or any other conditions above those indicated in the operational
section of this specification is not implied. Operation beyond
the maximum operating conditions for extended periods may
affect product reliability.
THERMAL RESISTANCE
Thermal performance is directly linked to printed circuit board
(PCB) design and operating environment. Careful attention to
PCB thermal design is required.
Table 3. Thermal Resistance
Package Type
θJA1
θJC2
Unit
CP-32-12
29.4
2.0
°C/W
1
Based on simulation with JEDEC standard JESD51, using a 2S2P board.
2
Based on simulation with JEDEC standard JESD51, using a 1S0P board.
ESD CAUTION
