SSM2212

Data Sheet

Rev. C | Page 4 of 12

ELECTRICAL CHARACTERISTICS—LFCSP PACKAGE

VCB = 15 V, IO = 100 µA, TA = 25°C, unless otherwise specified.

Table 2.

Parameter

Symbol

Test Conditions/Comments

Min

Typ

Max

Unit

DC AND AC CHARACTERISTICS

Current Gain1

hFE

IC = 1 mA, VCB = 15 V

300

1800

2400

IC = 1 mA, VCB = 0 V

200

1300

2200

IC = 100 µA, VCB = 15 V

350

2100

2500

IC = 100 µA, VCB = 0 V

250

1500

2300

Current Gain Match2

ΔhFE

100 µA ≤ IC ≤ 1 mA

0.5

Noise Voltage Density3

IC = 1 mA, VCB = 0 V

fO = 10 Hz

1.6

nV/√Hz

fO = 100 Hz

0.9

nV/√Hz

fO = 1 kHz

0.85

nV/√Hz

fO = 10 kHz

0.85

nV/√Hz

Low Frequency Noise (0.1 Hz to 10 Hz)

eN p-p

IC = 1 mA

0.4

µV p-p

Offset Voltage

VOS

VCB = 0 V, IC = 1 mA

250

µV

VCB = 0 V, IC = 100 µA

250

µV

Gain Bandwidth Product

IC = 10 mA, VCE = 10 V

200

MHz

Input Bias Current

IC = 100 µA

200

Input Offset Current

IOS

IC = 100 µA

Output Capacitance

COB

VCB = 15 V, IE = 0 µA

Collector-to-Collector Capacitance

CCC

VCC = 0 V

Current gain is guaranteed with collector-to-base voltage (VCB) swept from 0 V to VMAX at the indicated collector currents.

Current gain match (ΔhFE) is defined as follows: ΔhFE = (100(ΔIB)(hFE min)/IC).

Noise voltage density is guaranteed, but not 100% tested.
