Coaxial cable connection of Antennas, Sensors, and Communication Trunk Lines

GT1 Series

— Connectors for coaxial cables —

<Several types and configurations: In-line, board mounted, combinations of

coaxial cable with signal/power. Multi-position.

>

7

Features

Cost efficient termination

Highly efficient and reliable single motion crimp termination allows high volume production with semi-

automatic equipment.

Lock-release latching system

Shock / vibration resistant electrical connections

Verification of the full contact insertion

Excellent shielding effects.

Excellent High Frequency Performance

Refer to V.S.W.R. data on the following pages.

Termination of coaxial cables in automotive, medical and instrumentation applications

utilizes a single motion to crimp the center conductor, shield and outer Insulator.

The product information in this catalog is for reference only. Please request the Engineering Drawing for the most current and accurate design information.

All non-RoHS products have been discontinued, or will be discontinued soon. Please check the products status on the Hirose website RoHS search at www.hirose-connectors.com, or contact your Hirose sales representative.
