AM29SL400C Scheda tecnica(PDF) 39 Page - SPANSION |
|
|
|||||||||||||||||||||||||||||
AM29SL400C Scheda tecnica(HTML) 39 Page - SPANSION |
|
|
39 / 44 page  March 3, 2005 37 Ad vance Inform ati o n AC Characteristics tGHEL tWS OE# CE# WE# RESET# tDS Data tAH Addresses tDH tCP DQ7# DOUT tWC tAS tCPH PA Data# Polling A0 for program 55 for erase tRH tWHWH1 or 2 RY/BY# tWH PD for program 30 for sector erase 10 for chip erase 555 for program 2AA for erase PA for program SA for sector erase 555 for chip erase tBUSY Notes: 1. PA = program address, PD = program data, DQ7# = complement of the data written, DOUT = data written 2. Figure indicates the last two bus cycles of command sequence. 3. Word mode address used as an example. Figure 24. Alternate CE# Controlled Write Operation Timings |
|
