background image
SSM2517
Data Sheet
Rev. B | Page 4 of 16
Parameter
Symbol
Test Conditions/Comments
Min
Typ
Max
Unit
Standby Current
VDD = 1.8 V, fS = 64×
57
μA
VDD = 1.8 V, fS = 128×
114
μA
Shutdown Current
VDD = 3.3 V
3.0
μA
VDD = 1.8 V
0.9
μA
NOISE PERFORMANCE
Output Voltage Noise
en
Dithered input, A-weighted
PVDD = 3.6 V, fS = 64×
43
μV
PVDD = 3.6 V, fS = 128×
52
μV
PVDD = 5.0 V, fS = 64×
52
μV
PVDD = 5.0 V, fS = 128×
60
μV
Signal-to-Noise Ratio
SNR
PO = 1.38 W, PVDD = 5.0 V, RL = 8 Ω,
A-weighted
fS = 64×
96
dB
fS = 128×
95
dB
DIGITAL INPUT SPECIFICATIONS
Table 2.
Parameter
Symbol
Min
Typ
Max
Unit
INPUT SPECIFICATIONS
Input Voltage High
VIH
PCLK, PDAT, LRSEL Pins
0.7 × VDD
3.6
V
GAIN_FS Pin
1.35
5.5
V
Input Voltage Low
VIL
V
PCLK, PDAT, LRSEL Pins
−0.3
0.3 × VDD
V
GAIN_FS Pin
−0.3
+0.35
V
Input Leakage High
IIH
PDAT, LRSEL, GAIN_FS Pins
1
μA
PCLK Pin
3
μA
Input Leakage Low
IIL
PDAT, LRSEL, GAIN_FS Pins
1
μA
PCLK Pin
3
μA
Input Capacitance
5
pF
