ATR2740 [Preliminary]

4816BS–DAB–11/04

Figure 1. Block Diagram

ADC

ARM7TDMISy stem

RESET

DAB

ChannelDecoder

VINP

TXRDI

Signal

Processing

CORE

ADC_DATA

Clock

Generation

CAN

Adressbus

I2S/SPDIF

VINN

VCM

ATR2740

Databus

Control

USART1

USART2

SPI

SFCO

I2S/SPDIF

Watchdog

IRQ0

IRQ1

IRQ2

JTAG

SSO

USB

Adv anced

Power

Management

XO

GPIO

Watchdog

Absolute Maximum Ratings

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating

only and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of this

specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

Parameters

Symbol

Min.

Max.

Unit

Operating free air temperature range for LQFP128

-40

+85

° C

Operating free air temperature range for BGA121

-10

+70

° C

Storage temperature

T

Stg

-60

+150

° C

DC supply voltage

VDD18

-0.3

+1.95

V

VDD33

-0.3

+3.6

V

AVDD

-0.3

+3.6

V

DC input voltage

-0.3

+1.95

V

Notes:

1. The part may not survive if all maximums are applied simultaneously.

DC Electrical Characteristics

Test conditions (if not otherwise specified): V

No.

Parameters

Test Conditions

Pin

Symbol

Min.

Typ.

Max.

Unit

Type*

1.1

DC supply voltage

VDD18

1.65

1.8

1.95

V

1.2

Low-level input

voltage

VDD18 = 1.65 to 1.95 V

V

IL

-0.3

+0.3

×

VDD18

V

1.3

High-level input

voltage

VDD18 = 1.65 to 1.95 V

V

IH

+0.7

×

VDD18

VDD18

+ 0.3

V

1.4

Low-level output

voltage

I

VDD18 = 1.65 V

V

OL

0.1

V

*) Type means: A = 100% tested, B = 100% correlation tested, C = Characterized on samples, D = Design parameter
