background image
SEMICONDUCTOR
RoHS
RoHS
Nell High Power Products
40D(R)Series
ORDERING INFORMATION TABLE
1
Current rating: Code = IF(AV)
2
D = Standard recovery device
3
None = Stud normal polarity (cathode to stud)
4
R = Stud reverse polarity (anode to stud)
Device code
D
M
40
R
12
1
2
3
4
5
5
Voltage code
× 100 = VRRM (see Voltage Ratings table)
None = Stud base DO-203AB (DO-5) 1/4”-28 UNF-2A, standard type
M = Stud base DO-203AB (DO-5) M6
×1.0, standard type
Page 6 of 7
www.nellsemi.com
DO-203AB(DO-5), standard type
19(0.75)
Ø15.2(Ø0.598) Max
(0.24/0.28)
6.2/7.0
Ø4.0(Ø0.157)
1/4
” 28UNF-2A
For metric devices: M6x1.0
(0.028/0.043)
0.7/1.1
AII dimensions in millimeters (inches)
Glass-Metal Seal
-
-
-
-
-
S = Stud base DO-203AB (DO-5) M8
×1.0, “Semikron” type
