Technical Data 4365
Effective July 2017
Core loss vs Bp-p
Inductance characteristics
FP1505
High frequency, high current power inductor
Temperature rise vs total loss
50
45
40
35
30
25
20
15
10
5
0
0
0.4
0.8
1.2
1.6
2
T otal Lo ss (W)
1
500 300 200
100
M Hz
k
Hz
kHz kHz
kHz
10
1
0.1
0.01
0.001
0.0001
100
1000
10000
Bp-p (Gauss)
% of O C L vs. % of Isat1
100%
80%
+25°C
-40°C
60%
+125°C
40%
20%
0%
0%
20%
40%
60%
80%
100%
120%
140%
% of Isat 1
