 2 / 6 page
background image
HM6543
P.2
DUAL VOLTAGE
HIGH BRIGHTNESS
EL DRIVER IC
SPECIFICATION
(T=25℃, Vdd1=5.0V, Vdd2=8.0V Lamp Capacitacnce=30nF, Coil=680µf (R=5.5 ohms),
COSC=150pF, unless otherwise noted)
PARAMETER
MIN
TYP
MAX
UNIT
CONDITIONS
Supply Voltage, Vdd1
3.0
-
5.0
V
Supply Voltage, VDd2
3.0
-
12.0
V
Total Supply Current
-
-
100
mA
HON=5.0V
Vdd1=5.0V
Vdd2=8.0V
Quiescent Supply
Current
-
100
1000
nA
HON=0V
Vdd1=5.0V
Vdd2=12.0V
Hon Voltage, On
Vdd1-0.5
-
Vdd1
V
Hon Current, On
-
15
60
uA
Hon Voltage, Off
-
-
Vdd1-4
V
Vdd1=5.0V
INDUCTOR DRIVE
Peak Coil Current,
Ipk-coil
-
-
300
mA
Coil Duty Cycle
75
%
EL LAMP OUTPUT
EL Lamp
Frequescy,flamp
200
400
600
Hz
Vdd1=5.0V;
Vdd2=8.0V
Peak to Peak
Output Voltage
110
160
-
Vpp
Vdd1=5.0V;
Vdd2=8.0V
