Page 2 / 5

ABSOLUTE MAXIMUM RATINGS at TA=25°C

ELECTRICAL / OPTICAL CHARACTERISTICS at TA=25°C

Notes:

1. Measurement tolerance of the chromaticity coordinates is ± 0.01.

2. Forward voltage: ±0.1V.

3. Excess driving current and / or operating temperature higher than recommended conditions may result in severe light degradation or premature failure.

Notes:

1. 1/10 Duty Cycle, 0.1ms Pulse Width.

2. Rth JA ,Rth JS Results from mounting on PC board FR4 (pad size ≥ 16 mm

2 per pad).

3. Relative humidity levels maintained between 40% and 60% in production area are recommended to avoid the build-up of static electricity – Ref JEDEC/JESD625-A and JEDEC/J-STD-033.

Parameter

Symbol

Emitting Color

Value

Unit

Typ.

Max.

Chromaticity Coordinates x

IF = 20mA

x [1]

Pink

0.35

Chromaticity Coordinates y

IF = 20mA

y [1]

Pink

0.15

Capacitance

Pink

100

Forward Voltage IF = 20mA

[2]

Pink

3.3

4.0

Reverse Current (VR = 5V)

Pink

Temperature Coefficient of x

IF = 20mA, -10°C ≤ T ≤ 85°C

TCx

Pink

-0.15

10-3/°C

Temperature Coefficient of y

IF = 20mA, -10°C ≤ T ≤ 85°C

TCy

Pink

-0.18

10-3/°C

Temperature Coefficient of VF

IF = 20mA, -10°C ≤ T ≤ 85°C

TCV

Pink

-3.0

mV/°C

Parameter

Symbol

Unit

Power Dissipation

120

Reverse Voltage

Junction Temperature

100

°C

Operating Temperature

Top

-40 to +85

°C

Storage Temperature

Tstg

-40 to +85

°C

DC Forward Current

Peak Forward Current

IFM

[1]

100

Thermal Resistance (Junction / Ambient)

Rth JA

[2]

250

°C/W

Thermal Resistance (Junction / Solder point)

Rth JS

[2]

140

°C/W

Value

Electrostatic Discharge Threshold (HBM)

250

AA3528VRVCS/A
