AS03608MR-4-R

36mm Speaker

Mechanical and Environment Testing

Test Description

Test Condition

High Temperature

60°C with random humidity for 96 hours

Low Temperature

-30°C with random humidity for 96 hours

Humidity

40°C with 90% to 95% relative humidity for 96

hours

Power Test

1W white noise signal for 96 hours

Drop Test

75 cm free fall onto 5 mm thick board, 10 cycles

Temperature Cycle Test

-25°C to 60°C, five 60 minute cycles

After tests, speaker shall rest for 1 hours. SPL shall not deviate ±3 dB from pre-test measurement.

Frequency Response Measurement Setup
