Data Sheet

AS07808AS-R

PUI Audio’s Copperhead Series was conceived to create a family sound across

three different speaker sizes: 36mm, 53mm, and 78mm square. Specialized alloy

cones are paired with optimized motors to achieve superior frequency response

and output, with minimized harmonic distortion.

The eight ohm, 78mm square frame AS07808AS-R features a rubber surround,

for water and dust resistance, and a shielded double-stacked motor to protect

sensitive components and for high sensitivity.

Features:

•

Coated alloy cone for extended frequency response to 40 kHz

•

82 dB output at 1m (102 dB output at 10cm)

•

High-energy, double-stacked magnetic motor

•

Large 20mm diameter voice coil for high power handling

•

Easy-to-mount square frame

Specifications

Parameters

Values

Units

Rated Input Power

15

Watts

Max Input Power

30

Watts

Impedance

8 ± 15%

Ohms

Sensitivity (SPL @ 1W/1m)

Avg. at 2, 4, 8, and 16 kHz

82 ± 3

dB

Resonant Frequency

(in free air)

120±20%

Hz

Frequency Range (-20 dB)

60 ~ 40,000

Hz

Frame Material

Stamped Steel

-

Magnet Material

NdFeB

-

Weight

560

Grams
