KEMET Part Number: B-01-R

(UDLB00001R0000)

KEMET, BEAD L, DC Line Filters, Normal Mode

Dimensions

D

3.4mm +/-0.2mm

L

13mm MAX

LL

20mm MIN

S

5mm NOM

L2

4.4mm +/-0.2mm

Packaging Specifications

Packaging: Bulk

Packaging Quantity: 100

Weight: 400 mg

General Information

Series: BEAD L

Style: Through-Hole

RoHS: Yes

Specifications

Temperature Range: -20/+70°C
