Product data sheet

Characteristics

QO21251200

Mini CB, QO, 125 A, 2P, 120/240 V, 10 kA, Plug

in, Aux Switch 1A

Price** : 560.00 USD

Main

Product

Miniature circuit-breaker

Range

QO

Current Rating

125 A

Voltage Rating

120/240 V AC

120 V AC

Mounting Type

Plug-in

Number of Poles

2P

Circuit Breaker Type

Standard

Ratings

HACR rated

Electrical Connection

Box lugs

Options

Auxiliary switch 120 V AC 1A

Complementary

Inturrupt Rating

10 kA 120/240 V AC 50/60 Hz

10 kA 120 V AC 50/60 Hz

Number of Panel Spaces

3

Wire Size

AWG 4...AWG 2/0 copper or aluminium

Tightening torque

40.71 lbf.in (4.6 N.m)

Height

88.90 mm (3.5 in)

Depth

73.91 mm (2.91 in)

Width

57.15 mm (2.25 in)

Environment

Certifications

UL listed

CSA

Ambient Rating

104 °F (40 °C)

Dec 20, 2019

1
