CYNTEC CO., LTD.

乾坤科技股份有限公司

Oct., 2019

DOCUMENT

: SDER041H-000

REVISION

: B3

PAGE

: 1 OF 6

Sealed Choke Coil SDER041H type

 Features

Low profile：4.0mm x 4.0mm x 1.8mm

Low coil resistance with large currents.

High magnetic shield construction should actualize high resolution for EMC protection.

100% lead (Pb) free meet RoHS standard

 Application

Cellular phones, LCD displays, HDDs, DVCs, DSCs, PDAs etc..

 Outline Dimensions

L

T

W

Note：This graph is in regard to outline dimensions spec. For outer appearance, please refer to actual product.

Code

Dimensions (mm)

L

4.0

 0.2*

W

4.0

 0.2*

T

1.8 Max*

* Dimensions are of the case not including the

termination. For maximum overall dimensions

including the termination, add 0.1mm.
