PRODUCT

DATASHEET

CS15158_STRADA-IP-2X6-T4-B

STRADA-IP-2X6-T4-B

Wide IESNA Type IV beam with forward-throw

beam for wide area lighting like car parks

TECHNICAL SPECIFICATIONS:

Dimensions

71.4 x 173.0 mm

Height

10.6 mm

Fastening

screw

ROHS compliant

yes

MATERIAL SPECIFICATIONS:

Component

Type

Material

Colour

Finish

STRADA-IP-2X6-T4-B

Multi-lens

PMMA

clear

2X6-SEAL25

Seal

Silicone

white

ORDERING INFORMATION:

Component

Qty in box

MOQ

MPQ

Box weight (kg)

CS15158_STRADA-IP-2X6-T4-B

» Box size: 476 x 273 x 247 mm

Multi-lens

120

40

7.8

Last update: 20/12/2018

Subject to change without prior notice

Published: 29/07/2019

LEDiL is a registered trademark of LEDiL Oy in the European Union, USA, and certain other countries.

1/19
