Symbol

Dimensions

(mm)

Min.

Typ.

Max.

NOTES

A

0.90

1.00

1.10

A1

0.00

0.02

0.05

b

0.20

0.25

0.30

(1)

D

3.90

4.00

4.10

D2

2.55

2.60

2.65

E

3.90

4.00

4.10

E2

2.55

2.60

2.65

e

0.50

L

0.35

0.40

0.45

k

0.30

ddd

0.05

1.

Dimension “b” does not include dambar protrusion. Allowable dambar protrusion shall not cause the lead

width to exceed the maximum “b” dimension by more than 0.08 mm

TFQFPN 4 x 4 x 1.05 - 24 L

STSPIN830

TFQFPN 4x4x1.05 24L package information

DS12584 - Rev 2

page 21/27
