ADP1074

Data Sheet

Rev. D | Page 8 of 32

REGULATORY INFORMATION

See Table 4, Table 5, and the Insulation Lifetime section for details regarding recommended maximum working voltages for specific cross

isolation waveforms and insulation levels.

Table 4. Regulatory Information for Wide Body SOIC Package

UL (Pending)

CSA (Pending)

VDE (Pending)

CQC (Pending)

Recognized Under UL 1577

Component Recognition

Program1

Approved under CSA Component

Acceptance Notice 5A

Certified according to

DIN V VDE V 0884-10

(VDE V 0884-10):2006-122

Certified by

CQC11-471543-2012,

GB4943.1-2011:

Single Protection, 5000 V rms

Isolation Voltage

CSA 60950-1-07+A1+A2 and IEC 60950-1,

second edition, +A1+A2 and IEC62368:

Reinforced insulation,

maximum working

insulation voltage (VIORM) =

849 V peak,

highest allowable

overvoltage (VIOTM) =

8000 V peak

Basic insulation at 780 V rms

(1103 V peak)

Basic insulation at 780 V rms

(1103 V peak)

Reinforced insulation at 389 V rms

(552 V peak), tropical climate,

altitude ≤5000 meters

Reinforced insulation at 390 V rms

(552 V peak)

IEC 60601-1 Edition 3.1:

Basic insulation (1 means of patient

protection (1 MOPP)), 490 V rms

(686 V peak)

Reinforced insulation (2 MOPP),

238 V rms (325 V peak)

CSA 61010-1-12 and IEC 61010-1 third

edition:

Basic insulation at 300 V rms mains, 780 V

secondary (1103 V peak)

File (pending)

1 In accordance with UL 1577, each product is proof tested by applying an insulation test voltage ≥6000 V rms for 1 sec.

2 In accordance with DIN V VDE V 0884-10, each product is proof tested by applying an insulation test voltage ≥1592 V peak for 1 sec (partial discharge detection limit = 5 pC).

Note that the asterisk (*) marking branded on the component designates DIN V VDE V 0884-10 approval.

Table 5. Regulatory Information for LGA Package

UL (Pending)

CSA (Pending)

VDE (Pending)

CQC (Pending)

Recognized Under UL 1577

Component Recognition

Program1

Approved under CSA Component

Acceptance Notice 5A

Certified according to

DIN V VDE V 0884-10

(VDE V 0884-10):2006-122

Certified by

CQC11-471543-2012,

GB4943.1-2011:

Single Protection, 3000V rms

Isolation Voltage

CSA 60950-1-07+A1+A2 and IEC 60950-1,

second edition, +A1+A2 and IEC62368:

Reinforced insulation,

VIORM = 565 V peak,

VIOTM = 4242 V peak

impulse voltage =

4242 V peak

Basic insulation at 400 V rms

(565 V peak)

Basic insulation at 400 V rms (565 V peak)

Reinforced insulation at 200 V rms

(283 V peak), tropical climate,

altitude ≤5000 meters

Reinforced insulation at 200 V rms

(283 V peak)

IEC 60601-1 Edition 3.1:

Basic insulation (1 means of patient

protection (1 MOPP)), 250 V rms

(354 V peak)

CSA 61010-1-12 and IEC 61010-1 third

edition:

Basic insulation at 300 V rms mains, 400 V

secondary (565 V peak)

File (pending)

1 In accordance with UL 1577, each product is proof tested by applying an insulation test voltage ≥3000 V rms for 1 sec.

2 In accordance with DIN V VDE V 0884-10, each product is proof tested by applying an insulation test voltage ≥1059 V peak for 1 sec (partial discharge detection limit = 5 pC).

Note that the asterisk (*) marking branded on the component designates DIN V VDE V 0884-10 approval.
