pulled up to a 3.3 V supply with a pull-up resistor. The value of the resistor depends on total bus capacitance.
4.7 kΩ is a good first approximation for a bus capacitance of 10 pF.
Refer to the DS160PR412/421 Programming Guide for details.
Table 7-4. SMBUS/I2C Slave Address Settings
MODE
ADDR
7-bit Slave Address Channels 0-1 7-bit Slave Address Channels 2-3
L1
L0
0x18
0x19
L1
L1
0x1A
0x1B
L1
L2
0x1C
0x1D
L1
L3
0x1E
0x1F
L2
L0
0x20
0x21
L2
L1
0x22
0x23
L2
L2
0x24
0x25
L2
L3
0x26
0x27
www.ti.com
DS160PR412
SNLS685 – DECEMBER 2020
Copyright © 2020 Texas Instruments Incorporated
Submit Document Feedback
17
Product Folder Links: DS160PR412
