The LEI Series is designed specifically to enhance both PFM and

PWM application performance.Q(Rac) value at light load and the

RDC value at heavy load are both exceptional. Furthermore, the

saturated current performance is also optimal, helping to reduce the

ripple current and enhance the efficiency.

Features

Applications

 RoHS, Halogen Free and REACH Compliance

 High Efficiency

 Excellent Q, RDC and saturation current

 Low profile and miniature size down to 1.6*0.8*0.8mm

 Smartphones, tablets and wearable devices

 HDD, SSD and PC peripheral devices

 DSC, camcorders

 PND

 DC/DC converters

Product Identification

Shape and Dimensions

Recommended Pattern

Dimensions in mm

TYPE

A

B

C

D

160808A

1.6±0.2

0.80±0.2

0.8Max

0.3±0.2

201208A

2.0±0.2

1.25±0.2

0.8Max

0.5±0.3

201210A

2.0±0.2

1.25±0.2

1.0Max

0.5±0.3

201608A

2.0±0.2

1.60±0.2

0.8Max

0.5±0.3

201610A

2.0±0.2

1.60±0.2

1.0Max

0.5±0.3

252010A

2.5±0.3

2.00±0.3

1.0Max

0.6±0.3

252012A

2.5±0.3

2.00±0.3

1.2Max

0.6±0.3

322510A

3.2±0.3

2.50±0.3

1.0Max

0.5±0.3

322512A

3.2±0.3

2.50±0.3

1.2Max

0.5±0.3

322525A

3.2±0.3

2.50±0.3

0.5±0.3

Dimensions in mm

TYPE

A

B

C

160808A

0.7~0.8

1.8~2.0

0.8~1.1

201208A

0.8~1.2

2.3~2.9

1.0~1.45

201210A

0.8~1.2

2.3~2.9

1.0~1.45

201608A

0.7

2.3

1.8

201610A

0.7

2.3

1.8

252010A

1.2

2.8

2.3

252012A

1.2

2.8

2.3

322510A

1.7

3.5

2.8

322512A

1.7

3.5

2.8

322525A

1.7

3.5

2.8

Moiding power lnducto rs

LMI Series

L

Rev :

www.leiditech.com

01.06.2018

1/7
