ADPA9002

Data Sheet

Rev. 0 | Page 8 of 19

TYPICAL PERFORMANCE CHARACTERISTICS

–20

–10

–15

–5

100

200

300

400

500

FREQUENCY (MHz)

S11 (dB)

S21 (dB)

S22 (dB)

Figure 8. S22, S21, and S11 vs. Frequency, 10 MHz to 500 MHz,

Self Biased Mode, VDD = 12 V, VGG1 = GND

FREQUENCY (GHz)

TA = –40°C

TA = +25°C

TA = +85°C

Figure 9. Gain vs. Frequency for Various Temperatures, Self Biased Mode,

VDD = 12 V, VGG1 = GND

FREQUENCY (GHz)

300mA

400mA

385mA, SELF BIASED

500mA

Figure 10. Gain vs. Frequency for Various IDQ, Externally Biased Mode,

VDD = 12 V, Controlled VGG1

–20

–10

–15

–5

FREQUENCY (GHz)

S11 (dB)

S21 (dB)

S22 (dB)

Figure 11. S22, S21, and S11 vs. Frequency, 500 MHz to 16 GHz,

Self Biased Mode, VDD = 12 V, VGG1 = GND

FREQUENCY (GHz)

10V, 375mA

12V, 385mA

15V, 410mA

Figure 12. Gain vs. Frequency for Various VDD and Quiescent Currents,

Self Biased Mode, VGG1 = GND

–20

–16

–12

–8

–4

FREQUENCY (GHz)

TA = –40°C

TA = +25°C

TA = +85°C

Figure 13. Input Return Loss vs. Frequency for Various Temperatures,

Self Biased Mode, VDD = 12 V, VGG1 = GND
