MODEL: JFK

JFK SPECIFICATIONS

ES-1681 Rev.7 Page 2/3

http://www.m-system.co.jp/

SPECIFICATIONS OF OPTION: Q (multiple selections)

COATING (For the detail, refer to M-System's web site.)

/C01: Silicone coating

/C02: Polyurethane coating

/C03: Rubber coating

TERMINAL SCREW MATERIAL

/S01: Stainless steel

EQUATION

Equation parameters

X0: output (%)

X1 to X3: input (%)

K0 to K3: gain ±29.999

A0 to A3: bias (%) ±299.99 %

EQUATION

/1: Temp. & pressure compensation for DP owmeter (ideal gas)

K2X2+A2

X0 = K1X1

K3X3+A3

where X0 : compensated ow (linear characteristic)

X1 : uncompensated ow (sq. root extraction available)

X2 : pressure

X3 : temperature

/2: Addition/subtraction

X0 = K0 {K1 (X1+A1) + K2 (X2+A2) + K3 (X3+A3)} + A0

/3: Multiplication

X0 = K0 (K1X1+A1) (K2X2+A2) (K3X3+A3) + A0

/4: Multiplication/division

K0 (K1X1+A1) (K2X2+A2)

X0 =

+ A0

(K3X3+A3)

/5: Multiplication/division

K0 (K1X1+A1)

X0 =

+ A0

(K2X2+A2) (K3X3+A3)

/6: Addition/multiplication

X0 = K0 (K1X1+K2X2+A1) (K3X3+A3) + A0

/7: Addition/division

K0 (K1X1+K2X2+A1)

X0 =

+ A0

(K3X3+A3)

/8: Addition/division

K0 (K1X1+A1)

X0 =

+ A0

(K2X2+K3X3+A2)

/9: Addition/multiplication

X0 = K0 (K1X1+A1) + K0 (K2X2+A2) (K3X3+A3) + A0

/10: Addition/division

K0 (K2X2+A2)

X0 = K0 (K1X1+A1) +

+ A0

(K3X3+A3)

RELATED PRODUCTS

• Programming Unit (model: PU-2x)

• PC configurator software (model: JXCON)

Downloadable at M-System’s web site.

A dedicated cable is required to connect the module to the

PC. Please refer to the internet software download site or

the users manual for the PC configurator for applicable

cable types.

GENERAL SPECIFICATIONS

Construction: Plug-in

Connection: M3.5 screw terminals

Screw terminal: Chromated steel (standard) or stainless

steel

Housing material: Flame-resistant resin (black)

Isolation: Input to output to power (non-isolated between

inputs)

Overrange input: Approx. -25 to +125 %

Overrange output: Approx. -10 to +120 % at 1 – 5 V

Zero adjustment: -5 to +5 % (front)

Span adjustment: 95 to 105 % (front)

Adjustments: Programming Unit (model: PU-2x); equation

and parameters, square root extraction, zero and span, etc.

(Refer to the users manual of JXCON for the adjustments

configurable with JXCON.)

INPUT SPECIFICATIONS

■ DC Current: Input resistor incorporated

OUTPUT SPECIFICATIONS

■ DC Current: 0 – 20 mA DC

Minimum span: 1 mA

Offset: Max. 1.5 times span

Load resistance: Output drive 15 V max.

■ DC Voltage: -10 – +20 V DC

Span: Min. 5 mV, max. 20 V

Offset: Max. 1.5 times span

Load resistance: Output drive 1 mA max.; at ≥ 0.5 V

INSTALLATION

Power input

•AC: Operational voltage range: rating ±10 %,

50/60 ±2 Hz, approx. 3 VA

•DC: Operational voltage range: rating ±10 %,

ripple 10 %p-p max., approx. 2 W (90 mA at 24 V)

Operating temperature: -5 to +55°C (23 to 131°F)

Operating humidity: 30 to 90 %RH (non-condensing)

Mounting: Surface or DIN rail

Weight: 350 g (0.77 lb)
