www.ti.com

FEATURES

APPLICATIONS

1

2

3

4

8

7

6

5

GND1

OUT1

OUT2

GND2

VCC

IN1

IN2

AGC

AGC Control

P0026-03

DGK PACKAGE

(TOP VIEW)

DESCRIPTION

SN761663

SLES151 – OCTOBER 2005

AGC Amplifier

•

Low-Distortion AGC Amplifier

•

Wide Gain-Control Range

•

5-V Power Supply

•

8-Pin MSOP Package

•

Digital TV

•

Digital CATV, STB

The SN761663 is an AGC amplifier for the TV tuner

system of a digital TV, CATV, or STB. The circuit

consists

of

three

stages

of

controlled-gain

amplification,

followed

by

a

fixed-gain

output

amplifier.

The device is packaged in an 8-pin MSOP suitable

for surface mounting.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas

Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

PRODUCTION DATA information is current as of publication date.

Copyright © 2005, Texas Instruments Incorporated

Products conform to specifications per the terms of the Texas

Instruments standard warranty. Production processing does not

necessarily include testing of all parameters.
