MODEL: 73VR1100
73VR1100 SPECIFICATIONS
ES-7399 Rev.24 Page 6/18
https://www.m-system.co.jp/
EXTERNAL VIEW
■ FRONT VIEW
■ REAR VIEW
(2) Front Cover
(6) CF Card Access Indicator LED
(7) USB Connector
(3) CF Card Slot
(4) Eject Button
(5) Reset Button
(1) Touch Panel Screen
(13) RUN Output Terminal
(9) LAN Port
(14) Alarm Output Terminal
(12) Power Input Terminal
(11) Power Indicator LED
(10) RUN Output Indicator LED
(8) RS-485 Terminal Block
FG
ALM
+
ALM
–
U
(+)
V
(–)
RUN
+
RUN
–
