Product data sheet

09 11 001 2671

Han 1HC-Sti-Ax 650A, 70-120mm²

Technical characteristics

Mating cycles

≥500

Material properties

Material (insert)

Polycarbonate (PC)

Polyamide (PA)

Colour (insert)

RAL 7032 (pebble grey)

Material (contacts)

Copper alloy

Surface (contacts)

Silver plated

Material flammability class acc. to UL 94

V-0

RoHS

compliant with exemption

RoHS exemptions

6(a) / 6(a)-I: Lead as an alloying element in steel for machining purposes and

in galvanised steel containing up to 0,35 % lead by weight / Lead as an alloying

element in steel for machining purposes containing up to 0,35 % lead by weight

and in batch hot dip galvanised steel components containing up to 0,2 % lead by

weight

6(c): Copper alloy containing up to 4 % lead by weight

ELV status

compliant with exemption

China RoHS

50

REACH Annex XVII substances

No

REACH ANNEX XIV substances

No

REACH SVHC substances

Yes

REACH SVHC substances

Lead

Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate

Specifications and approvals

Specifications

EN 60664-1

IEC 61984

Approvals

DNV GL

UL / CSA

UL 1977 ECBT2.E235076

CE

0

Commercial data

Packaging size

1

Net weight

364 g

Country of origin

Romania

European customs tariff number

85359000
