Data Sheet
ADRF6614
Rev. 0 | Page 55 of 61
EVALUATION BOARD
An evaluation board is available for the ADRF6614. The standard
evaluation board schematic is presented in Figure 119. The USB
interface circuitry schematic is presented in Figure 121 and/or
Figure 120. The evaluation board layout is shown in Figure 122
and Figure 123. The evaluation board is fabricated using
Rogers® 3003 material. Table 47 details the configuration for the
mixer characterization. The evaluation board software is
available on www.analog.com.
