ADRF6720
Data Sheet
Pin No.
Mnemonic
Description
30
VPOS6
3.3 V Supply Voltage for VCO LDO. Decouple VPOS6 with 100 pF and 0.1 µF
capacitors located close to the pin.
31
DECL3
Decoupling Pin for VCO LDO. Connect 100 pF, 0.1 µF, and 10 µF capacitors between
this pin and ground.
32
VTUNE
VCO Tuning Voltage.
33, 34
LOIN−, LOIN+
Differential External LO Inputs.
35
VPOS7
3.3 V Supply Voltage for Charge Pump. Decouple VPOS7 with 100 pF and 0.1 µF
capacitors located close to the pin.
36
CP
Charge Pump Output.
37
GND
Charge Pump Ground.
38
GND
PLL Reference Ground.
39
REFIN
PLL Reference Input.
40
VPOS8
3.3 V Supply Voltage for PLL Reference. Decouple VPOS8 with 100 pF and 0.1 µF
capacitors located close to the pin.
EP
Exposed Pad. Solder the exposed pad to a low impedance ground plane.
Rev. 0 | Page 10 of 44
