ADRF6780
Data Sheet
Rev. D | Page 8 of 35
Pin No.
Mnemonic
Description
27, 31
VPLO
Power Supply Connections for the LO Path. Decouple the VPLO pin with 100 pF and 0.1 µF capacitors as close
as possible to the pin.
28, 30
LOIN, LOIP
LO Inputs. These inputs are 100 Ω differential inputs for the LO path. The LO input frequency range is 5.4 GHz
to 14 GHz. The on-chip LO frequency doubler can be enabled via a SPI command.
32
ALM
Alarm. The ALM pin indicates internal alarm conditions. The ALM pin is logic low when an alarm condition is
detected.
EP
Exposed Pad. Solder the exposed pad to a low impedance ground plane.
