7.4

SO14 package information

Dimensions (1)

Symbol

Millimeters

Inches

Min.

Typ.

Max.

Min.

Typ.

Max.

A

1.35

1.75

0.05

0.068

A1

0.10

0.25

0.004

0.009

A2

1.10

1.65

0.04

0.06

B

0.33

0.51

0.01

0.02

C

0.19

0.25

0.007

0.009

D (2)

8.55

8.75

0.33

0.34

E

3.80

4.0

0.15

0.15

e

1.27

0.05

H

5.80

6.20

0.22

0.24

L

0.40

1.27

0.015

0.05

k

0°

8°

0°

8°

ddd

0.10

0.004

1. Drawing dimensions include “Single” and “Matrix” versions.

2. Dimension “D” does not include mold flash, protrusions or gate burrs. Mold flash, protrusions or gate burrs shall not exceed

0.15 mm per side.

TSB711, TSB711A, TSB712, TSB712A, TSB714, TSB714A

SO14 package information

DS12487 - Rev 6

page 28/36
