PLL502-26

High Pull-Range VCXO (27MHz) with integrated Audio PLL

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/17/04 Page 4

5. DC Specification

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Supply Current, Dynamic,

with Loaded Outputs

Ouput load of 10pF

30

35

mA

Operating Voltage

2.97

3.63

V

10

mA

Output drive current

10

mA

Short Circuit Current

±50

mA

VCXO Control Voltage

VCON

0

3.3

V

6. Crystal Specifications

PARAMETERS

SYMBOL

MIN.

TYP.

MAX.

UNITS

Crystal Resonator Frequency

27

MHz

Crystal Loading Capacitance Rating

9.5

pF

C0/C1

250

-

ESR

30

Ω

Note: Crystal Loading rating: 9.5pF is the loading the crystal sees from the VCXO chip at VCON = 1.65V. It is assumed that the crystal will be at

nominal frequency at this load. If the crystal requires more load to be at nominal frequency, the additional load must be added externally.

This however may reduce the pull range.
