MHCI04020 Series Specification

6 Configuration and Dimensions:

7 Electrical Characteristics:

Inductance

Tolerance

Test Freq.

Irms(A)

Isat(A)

RDC(m )

Marking

(uH )

(±%)

Typ.

Typ.

Max.

MHCI04020-R10M-R8

0.1

20

100kHz,0.5V

12

25

4.0(3.5typ)

R10

MHCI04020-R22M-R8

0.22

20

100kHz,0.5V

9

12.5

6.6(6.0typ)

R22

MHCI04020-R47M-R8

0.47

20

100kHz,0.5V

7

9.5

14(12.5typ)

R47

MHCI04020-R56M-R8

0.56

20

100kHz,0.5V

6.5

10

16(14typ)

R56

MHCI04020-R68M-R8

0.68

20

100kHz,0.5V

5.2

8

21(19.4typ)

R68

MHCI04020-1R0M-R8

1

20

100kHz,0.5V

4.5

7

27(24typ)

1R0

MHCI04020-1R5M-R8

1.5

20

100kHz,0.5V

4

6

46(38typ)

1R5

MHCI04020-2R2M-R8

2.2

20

100kHz,0.5V

3

5

58(52typ)

2R2

MHCI04020-3R3M-R8

3.3

20

100kHz,0.5V

2.5

4

87(74typ)

3R3

MHCI04020-4R7M-R8

4.7

20

100kHz,0.5V

2.2

3

126(105typ)

4R7

MHCI04020-6R8M-R8

6.8

20

100kHz,0.5V

2

2.5

135(112typ)

6R8

MHCI04020-8R2M-R8

8.2

20

100kHz,0.5V

2

2.5

216(180typ)

8R2

MHCI04020-100M-R8

10

20

100kHz,0.5V

1.6

2

258(225typ)

100

`

Note:

5.Absolute maximum voltage 30VDC

should be verified in the end application.

Circuit design 125°C under worst case operating conditions. Component placement, PWB trace size

and thickness, airflow and other cooling provisions all affect the part temperature. Part temperature

Part No.

2.Isat for Inductance drop 30% from its value without current.

4.The part temperature (ambient + temp rise) should not exceed 125°C under worst case operating conditions.

1.Operating temperature range -55

℃~125℃(Including self - temperature rise)

3.Irms for a 40

℃ temperature rise from 25℃ ambient.

MHCI0402-2R2M-R8

Rev :

www.leiditech.com

01.06.2015

3/7
