THERMAL SHUTDOWN

In the event that the ADP5091/ADP5092 junction temperature

rises above 142°C, the thermal shutdown circuit turns off the

switch between the BAT pin and the SYS pin to prevent the

damage of the energy storage at a high ambient temperature. In

addition, the boost operation terminates. A 15°C hysteresis is

included, allowing the ADP5091/ADP5092 to return to operation

when the on-chip temperature drops to less than 127°C. When

exiting thermal shutdown, the boost and the energy storage

controller resume their functions.

Table 8. Programming Threshold Resistors (See Figure 42)

Voltage Threshold (V)

RBK1, RSD1, and RPG1 (MΩ)

RBK2, RSD2, and RPG2 (MΩ)

RTERM1 (MΩ)

RTERM2 (MΩ)

Not applicable

2.1

5.23

4.75

Not applicable

2.2

5.49

4.53

3.2

6.81

2.3

5.62

4.32

3.48

6.49

2.4

5.9

4.12

3.74

6.2

2.5

6.04

2.6

6.19

3.83

4.22

5.76

2.7

6.34

3.74

4.42

5.6

2.8

6.49

3.57

4.64

5.36

2.9

6.6

3.48

4.87

5.23

6.65

3.32

3.1

6.8

3.24

5.11

4.87

3.2

6.81

3.09

5.36

4.7

3.3

6.98

3.01

5.49

4.53

3.4

6.98

2.94

5.6

4.42

3.5

7.15

2.87

5.76

4.3

3.6

7.15

2.8

5.9

4.12

3.7

7.32

2.7

5.9

4.02

3.8

7.32

2.61

6.04

3.92

3.9

7.5

2.55

6.19

3.83

7.5

2.5

6.2

3.74

4.1

7.5

2.43

6.34

3.65

4.2

7.68

2.37

6.49

3.57

4.3

7.68

2.32

6.49

3.48

4.4

7.68

2.26

6.6

3.4

4.5

7.87

2.21

6.65

3.32

4.6

7.87

2.15

6.8

3.24

4.7

7.87

2.15

6.81

3.2

4.8

7.87

2.1

6.81

3.09

4.9

7.87

2.05

6.98

3.09

8.06

6.98

5.1

8.06

1.96

6.98

2.94

5.2

8.06

1.91

7.15

2.87
