1 / 15 page  April.2003 (Rev.1) - 1 - IP1621 DUAL OUTPUT VOLTAGE LDO REGULATOR + RESET IC www.interpionsemi.com - 1-Fixed 3.4V LDO regulator with internal NPN TR. - 1-Fixed 2.67V LDO regulator with internal NPN TR. - Typical reset detection voltage of 4.2V. - Built-in TSD circuit. - Built-in current limit circuit. - Built-in over voltage protection circuit. - Output voltage trimmed to +/-3% tolerance. DESCRIPTION FEATURES Device Package Operating Temp IP1621 14SOPH-8L -35 OC ~ +85OC ORDERING INFORMATION 14SOPH-8L BLOCK DIAGRAM The IP1621 is an integrated circuit that has triple LDO regulators and one reset circuit. All the LDO regulators have their own internal npn power transistors and their nominal output voltages are 2.67V and 3.4V, respectively. The reset circuit monitors the status of the regulator input voltage and outputs the RESET signal. RESET becomes high after the delay time that is determined by the exter- nal capacitor at Td pin. The delay time begins to start after the input voltage reaches above 4.2V. |
