Data Sheet

AD8555

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Supply Voltage

6 V

Input Voltage

VSS − 0.3 V to VDD + 0.3 V

Differential Input Voltage1

±5.0 V

Output Short-Circuit

Duration to VSS or VDD

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature Range

(Soldering, 10 sec)

300°C

Differential input voltage is limited to ±5.0 V or ± the supply voltage,

whichever is less.

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

Table 4.

Package Type

θJA1

θJC

Unit

8-Lead SOIC (R)

158

°C/W

16-Lead LFCSP (CP)

31.5

°C/W

θJA is specified for the worst-case conditions, i.e., θJA is specified for device

soldered in circuit board for SOIC and LFCSP packages.

ESD CAUTION

Rev. B | Page 7 of 29
