CRO2170B datasheet(2/2 Pages) ZCOMM

2 / 2 page

1950

2000

2050

2100

2150

2200

2250

2300

2350

00.5

11.5

2.5

33.5

4.5

-1

2010

2040

2069

2099

2130

2164

2199

2233

2264

2289

LOW COST - HIGH PERFORMANCE

VOLTAGE CONTROLLED OSCILLATOR

Page 2

Printed in the U.S.A.

CRO2170B

TUNING CURVE, typ.

POWER CURVE, typ.

PAGE 2

PHYSICAL DIMENSIONS

°c

-40

°c

0.475

0.000

0.025

0.500

0.405

0.305

0.205

0.105

0.115

0.215

0.315

0.415

GROUND PLANE SOLDER PLATED

BOTTOM VIEW

.037

SEE NOTE 3

TYPICAL OF ALL PADS

.026

.031

.052

.114

.070

TABS RANGE:

SEE NOTE 5.

(4 PLACES)

DETAIL A

P1=VT

P2=RF OUT

P3=Vcc

.220

.034

0.000

.070 TYP

.150

TYP

MINI-16

415-0061 REV. D

(DRAWING NOT TO SCALE)

SEE DETAIL 'A'

NOTES:

THE INSIDE RADIUS OF ALL 16 HALF HOLES

AT THE PERIMETER OF THE BOARD ARE

PLATED TO PROVIDE A SURFACE FOR THE

ATTACHMENT OF THE VCO TO A PCB,

IN 13 LOCATIONS, WITH 3 PADS BEING

USED FOR ELECTROMECHANICAL INTERFACE.

2. THE SURFACE OF THE SHIELD IS TIN PLATED

AND MAY BE SOLDERED TO. THE SHIELD'S

3. THE GROUND PLANE IS GROUND AND ATTACHES

TO A GROUND TRACK ON THE UPPER SIDE OF

THE BOARD AS WELL AS THE SHIELD BY PTH.

16 SOLDER LOCATIONS REQUIRED.

BASE METAL IS COLD ROLLED STEEL.

.XXX= ± .010

TOLERANCES

4. UNLESS OTHERWISE NOTED ALL DIMENSIONS

ARE IN INCHES.

5. UNLESS OTHERWISE NOTED ALL TOLERANCES

ARE AS FOLLOWS:

TUNING VOLTAGE (Vdc)

FREQUENCY (MHz)
