CC400

SWRS050

Page 1 of 32

CC400

Single Chip High Performance RF Transceiver

Applications

• UHF wireless data transmitters and

receivers

• Wireless alarm and security systems

• 315 / 426 / 429 / 433 MHz ISM/SRD

band systems

• Point of sale terminals

• Remote control systems

• Home security and automation

• Low power telemetry

• AMR – Automatic Meter Reading

• Environmental control

Product Description

CC400 is a single-chip high performance,

half-duplex,

FSK,

UHF

transceiver

designed for low power and low-voltage

wireless applications. The circuit is mainly

intended for the ISM (Industrial, Scientific

and Medical) frequency bands at 315, 418

and 433 MHz, but can easily be

programmed

for

operation

at

other

frequency bands in the 300 - 500 MHz

range.

The main operating parameters of

CC400

can be programmed via a serial interface,

thus making

CC400 a very flexible and

easy to use component. In a typical

system

CC400 will be used together with a

microcontroller and a few external passive

components.

CC400 is based on Chipcon’s SmartRF®

technology.

Features

• Single chip RF transceiver

• Frequency range 300 – 500 MHz

• High sensitivity (typical -110 dBm)

• Programmable output power up to 25

mW (14 dBm)

• Small size (SSOP-28 package)

• Low supply voltage (2.7 V to 3.3 V)

• Very few external components required

• FSK modulation

• Very low phase noise

• Data-rate up to 9.6 kbps

• Suitable for both narrow and wide band

systems

• Suitable

for

frequency

hopping

protocols

• Frequency-Lock indicator

• Development kit available

• Easy-to-use software (SmartRF Studio)

for generating the

CC400 configuration

data
