unit: mm

1

Intelligent Power Devices (IPDs)

1: IN

2: Drain

3: Source

EIAJ: SC-62

Mini-Power Type Package (3-pin)

4.5±0.1

3.0±0.15

1.5±0.1

0.4±0.08

0.5±0.08

1.5±0.1

0.4±0.04

1.6±0.2

45˚

marking

321

Gate cut-off circuit

ESD

protection

Over current

protection

Over voltage

protection

S

IN

D

Short circuit load

protection

Over heat

protection

MIP708

Silicon MOS IC

s Features

q 3-pin intelligent power device

q Five protective functions (over-current, over-voltage, short circuit

load, over heat, ESD) built-in

q Acceptable both AC and DC power supply

s Applications

q For lamp and solenoid drive

s Block Diagram

Parameter

Output voltage

Output peak current

Output current

Input voltage

Input current

Drain clamp energy

Allowable power

dissipation

Operating ambient temperature

Channel temperature

Storage temperature

Symbol

Ratings

40

±3

±1

− 0.5 to 6

±5

1

2

2

−40 to +125

150

−55 to +150

Unit

V

A

A

V

mA

mJ

W

W

°C

°C

°C

board is 1.7mm.)

Ta = 25°C
