 5 / 45 page
background image
#
Pin
Description
11
ILIM
A pull-down resistor to GND selects the
peak current limitation
12
DIM
A PWM signal in this input pin
implements the LED PWM current
dimming. It is pulled-down by internal 2
µA current
13
LX
Switching node
14
LX
Switching node
15
BOOT
Connect an external capacitor (100 nF
typ.) between BOOT and LX pins. The
gate charge required to drive the internal
n-DMOS is recovered by an internal
regulator during the off-time
16
GND
Signal GND
--
E.P.
Exposed pad must be connected to
GND plane
3.3
Maximum ratings
Stressing the device above the rating listed in may cause permanent damage to the device. These are stress
ratings only and operation of the device at these or any other conditions above those indicated in the operating
sections of this specification is not implied. Exposure to absolute maximum rating conditions may affect device
reliability.
Table 2. Absolute maximum ratings
Symbol
Description
Min.
Max.
Unit
VIN
-0.3
61
V
VCC
-0.3
61
V
BOOT
VBOOT - GND
-0.3
65
V
VBOOT – VLX
-0.3
4
V
VBIAS
-0.3
VCC
V
EN
-0.3
VCC
V
DIM
-0.3
VCC
V
LX
-0.3
VIN+0.3
V
SYNCH
-0.3
5.5
V
SS
-0.3
3.6
V
FSW
-0.3
3.6
V
COMP
-0.3
3.6
V
ILIM
-0.3
3.6
V
FB
-0.3
3.6
V
TJ
Operating temperature
range
-40
150
°C
TSTG
Storage temperature
range
-65
150
°C
TLEAD
Lead Temperature
(soldering 10 s)
260
°C
IHS
High-side RMS current
3
A
ALED6000
Maximum ratings
DS13018 - Rev 4
page 5/45
